Gradle 都做了哪些缓存？

前言

Gradle是Android的构建工具，它的主要目标就是实现快速的编译构建，而这主要就是通过缓存实现的。本文主要介绍Gradle的缓存机制，具体包括以下内容

Gradle缓存机制
Gradle内存缓存
Gradle项目缓存
Gradle本机缓存
Gradle远程缓存

使用allowInsecureProtocol属性解决gradle的仓库地址不安全警告

使用 allowInsecureProtocol 属性解决 gradle 的仓库地址不安全警告，在 IDEA 的 Terminal 中使用命令

$ gradlew --warning-mode all

1	$ gradlew --warning-mode all

可以打印出当前 gradle 存在的所有警告信息。

如果有报以下警告：

Using insecure protocols with repositories, without explicit opt-in, has been deprecated. This is scheduled to be removed in Gradle 7.0. Switch Maven repository 'm
aven(http://maven.aliyun.com/nexus/content/groups/public/)' to a secure protocol (like HTTPS) or allow insecure protocols. See https://docs.gradle.org/6.8.3/dsl/or
g.gradle.api.artifacts.repositories.UrlArtifactRepository.html#org.gradle.api.artifacts.repositories.UrlArtifactRepository:allowInsecureProtocol for more details.
Configuration on demand is an incubating feature.

Using insecure protocols with repositories, without explicit opt-in, has been deprecated. This is scheduled to be removed in Gradle 7.0. Switch Maven repository 'm

aven(http://maven.aliyun.com/nexus/content/groups/public/)' to a secure protocol (like HTTPS) or allow insecure protocols. See https://docs.gradle.org/6.8.3/dsl/or

g.gradle.api.artifacts.repositories.UrlArtifactRepository.html#org.gradle.api.artifacts.repositories.UrlArtifactRepository:allowInsecureProtocol for more details.

Configuration on demand is an incubating feature.

说明你配置了除 maven 中央仓库之外的其他不安全的仓库（至于“不安全”在这里的定义，我也不是很清楚，一些国内的镜像仓库例如阿里的也是“不安全”的）gradle 中有一个属性可以允许 gradle 使用“不安全”的仓库并且不报警告信息，该属性是 allowInsecureProtocol，官方的

Description ：Specifies whether it is acceptable to communicate with a repository over an insecure HTTP connection.

1	Description ：Specifies whether it is acceptable to communicate with a repository over an insecure HTTP connection.

翻译过来就是指定通过不安全的HTTP连接与仓库通信是否可接受，如果该属性的值设置为 true，则表示接受“不安全”的仓库地址。

目前，升级项目的 gradle 到 7.0.2 版本之后，报错如下：

* What went wrong:
A problem occurred configuring root project 'xxxx'.
> Could not resolve all dependencies for configuration ':classpath'.
   > Using insecure protocols with repositories, without explicit opt-in, is unsupported. Switch Maven repository 'maven(http://xxx.xxx.xxx.xxx/jcenter/)' to red
irect to a secure protocol (like HTTPS) or allow insecure protocols. See https://docs.gradle.org/7.0.2/dsl/org.gradle.api.artifacts.repositories.UrlArtifactRepos
itory.html#org.gradle.api.artifacts.repositories.UrlArtifactRepository:allowInsecureProtocol for more details.

* Try:
Run with --stacktrace option to get the stack trace. Run with --info or --debug option to get more log output. Run with --scan to get full insights.

* What went wrong:

A problem occurred configuring root project 'xxxx'.

> Could not resolve all dependencies for configuration ':classpath'.

> Using insecure protocols with repositories, without explicit opt-in, is unsupported. Switch Maven repository 'maven(http://xxx.xxx.xxx.xxx/jcenter/)' to red

irect to a secure protocol (like HTTPS) or allow insecure protocols. See https://docs.gradle.org/7.0.2/dsl/org.gradle.api.artifacts.repositories.UrlArtifactRepos

itory.html#org.gradle.api.artifacts.repositories.UrlArtifactRepository:allowInsecureProtocol for more details.

* Try:

Run with --stacktrace option to get the stack trace. Run with --info or --debug option to get more log output. Run with --scan to get full insights.

只需要在 build.gradle 中进行如下的配置即可：

repositories {
	...

    maven {
        allowInsecureProtocol = true
        ...
    }
}

repositories {

...

maven {

allowInsecureProtocol = true

...

}

参考链接

使用 allowInsecureProtocol 属性解决 gradle 的仓库地址不安全警告

gradle cache目录(.gradle)剖析

gradle下载后会对文件路径进行修饰，本文给出反向解析，把文件路径修改为原始路径的办法。

之所以研究这个，本来的目的是为了让Gradle支持离线编译，但是由于Gradle目录组织的缺陷，如.gradle/caches/modules-2/metadata-2.23(metadata-xx跟使用的gradle版本有关)目录下module-artifacts.bin等bin文件中存的是本机的绝对路径，导致就算将.gradle拷贝给另一台机器，还是需要联网验证。

将gradle的jcenter重定向的方法见我的另一篇文章：[android]gradle下载加速 - 知乎专栏，例如阿里云的jcenter是Index of /repositories/jcenter

我在内网中搭建了jcenter仓库。然而我不想搭建一个大而全的jcenter的仓库，搭建大而全的仓库可以使用nexus来搭建，阿里云也是那么搭的，由于公司的网络需要上网认证，时不时会断一下，所以我的做法是通过利用.gradle目录来创建jcenter仓库。

下面先介绍.gradle目录的组织。

1 .gradle顶级目录

目录| 功能
caches | gradle缓存目录
daemon | daemon日志目录
native | gradle平台相关目录
wrapper | gradle-wrapper下载目录

2 caches目录

目录 | 功能
2.14.1 | gradle程序的脚本（gradle程序版本）
3.2.1 | gradle程序的脚本（gradle程序版本）
jars-1 | ?
jars-2 | ?
modules-2 | 下载缓存目录

2.1 caches/modules-2目录

目录 | 功能
files-2.1 | gradle下载的jar/aar目录
metadata-2.16 | gradle-2.14.1的描述文件？
metadata-2.23 | gradle-3.2.1的描述文件？

2.1.1 files-2.1的目录组织（jar/aar都下载到这里）

${org}/${package}/${version}/${shanum1}/${package-version}.pom
${org}/${package}/${version}/${shanum2}/${package-version}.jar

1 2	${org}/${package}/${version}/${shanum1}/${package-version}.pom ${org}/${package}/${version}/${shanum2}/${package-version}.jar

例如：

#jcenter上jar的路径
https://jcenter.bintray.com/com/android/tools/lint/lint-api/25.1.3/lint-api-25.1.3.jar
#对应的缓存目录为
.gradle/caches/modules-2/files-2.1/com.android.tools.lint/lint-api/25.1.3/${shasum1}/lint-api-25.1.3.jar

#看下这个目录下有什么？
~ find .gradle/caches/modules-2/files-2.1/com.android.tools.lint/lint-api/25.1.3/ -type f
#除了jar包还有pom，用于描述jar。
.gradle/caches/modules-2/files-2.1/com.android.tools.lint/lint-api/25.1.3/14c6a94811fb8114a61b8f3ab29214f9466b5c59/lint-api-25.1.3.jar
.gradle/caches/modules-2/files-2.1/com.android.tools.lint/lint-api/25.1.3/c4844e26d84dd1f450f90d89d7e2d2d09f52760/lint-api-25.1.3.pom

#看下jar的shasum
~ shasum .gradle/caches/modules-2/files-2.1/com.android.tools.lint/lint-api/25.1.3/14c6a94811fb8114a61b8f3ab29214f9466b5c59/lint-api-25.1.3.jar

14c6a94811fb8114a61b8f3ab29214f9466b5c59  .gradle/caches/modules-2/files-2.1/com.android.tools.lint/lint-api/25.1.3/14c6a94811fb8114a61b8f3ab29214f9466b5c59/lint-api-25.1.3.jar
#即目录名。

#jcenter上jar的路径

https://jcenter.bintray.com/com/android/tools/lint/lint-api/25.1.3/lint-api-25.1.3.jar

#对应的缓存目录为

.gradle/caches/modules-2/files-2.1/com.android.tools.lint/lint-api/25.1.3/${shasum1}/lint-api-25.1.3.jar

#看下这个目录下有什么？

~ find .gradle/caches/modules-2/files-2.1/com.android.tools.lint/lint-api/25.1.3/ -type f

#除了jar包还有pom，用于描述jar。

.gradle/caches/modules-2/files-2.1/com.android.tools.lint/lint-api/25.1.3/14c6a94811fb8114a61b8f3ab29214f9466b5c59/lint-api-25.1.3.jar

.gradle/caches/modules-2/files-2.1/com.android.tools.lint/lint-api/25.1.3/c4844e26d84dd1f450f90d89d7e2d2d09f52760/lint-api-25.1.3.pom

#看下jar的shasum

~ shasum .gradle/caches/modules-2/files-2.1/com.android.tools.lint/lint-api/25.1.3/14c6a94811fb8114a61b8f3ab29214f9466b5c59/lint-api-25.1.3.jar

14c6a94811fb8114a61b8f3ab29214f9466b5c59 .gradle/caches/modules-2/files-2.1/com.android.tools.lint/lint-api/25.1.3/14c6a94811fb8114a61b8f3ab29214f9466b5c59/lint-api-25.1.3.jar

#即目录名。

注意：创建jcenter时，对于jar包，可以没有pom，但是如果使用aar，则必须有pom，所以最好是每个版本都有个pom。因为pom中也描述了依赖关系。

3 daemon目录（无需离线）

用于存放gradle daemon的运行日志。按gradle程序版本存放。

目录 | 功能
2.14.1 | gradle-2.14.1运行的日志
3.2.1 | gradle-3.2.1运行的日志

4 native目录（无需离线）

用于存放平台相关（Windows/Linux/Mac）的库。

目录 | 功能
19 | gradle-2.14.1对应的lib目录，按平台存放，如osx-amd64
21 | gradle-3.2.1对应的lib目录，按平台存放，如osx-amd64
jansi | ?

5 wrapper目录

用于存放gradle-wrapper下载gradle的zip包和解压后的文件夹。
wrapper的目录规则是
wrapper/dists/gradle-2.14.1-all/${base36}/gradle-2.14.1-all.zip
wrapper/dists/gradle-2.14.1-all/${base36}/gradle-2.14.1-all.zip.lck
wrapper/dists/gradle-2.14.1-all/${base36}/gradle-2.14.1-all.zip.ok

其中base36的规则为：

从gradle/wrapper/gradle-wrapper.properties中得到distributionUrl，即https://services.gradle.org/distributions/gradle-2.14.1-all.zip，注意文件中的\不算。
对distributionUrl计算md5。例如printf “https://services.gradle.org/distributions/gradle-2.14.1-all.zip” | md5
得到8c9a3200746e2de49722587c1108fe87。
利用0x8c9a3200746e2de49722587c1108fe87构造一个uint 128位整数。
将整数利用base36得到base36的值（取小写）。

从gradle-wrapper的jar包中提取的Java代码如下：

import java.math.BigInteger;
import java.security.MessageDigest;

public class Hash {

    public static void main(String[] args) {
        try {
            MessageDigest messageDigest = MessageDigest.getInstance("MD5");
            byte[] bytes = args[0].getBytes();
            messageDigest.update(bytes);
            String str = new BigInteger(1, messageDigest.digest()).toString(36);
            System.out.println(str);
        } catch (Exception e) {
            throw new RuntimeException("Could not hash input string.", e);
        }
    }
}

import java.math.BigInteger;

import java.security.MessageDigest;

public class Hash {

public static void main(String[] args) {

try {

MessageDigest messageDigest = MessageDigest.getInstance("MD5");

byte[] bytes = args[0].getBytes();

messageDigest.update(bytes);

String str = new BigInteger(1, messageDigest.digest()).toString(36);

System.out.println(str);

} catch (Exception e) {

throw new RuntimeException("Could not hash input string.", e);

}

c++跟java代码见http://github.com/xiaoyur347/gradlew/helper。

6. 使用.gradle/caches/modules-2创建jcenter的方法

以下是mirror.sh，我把它放在.gradle目录下。运行脚本会在.gradle目录下生成jcenter目录。把它移走或直接把jcenter目录加入http服务器即可。

目前我的做法是在本地使用gradle编译一次，然后把gradle下载下来的jar/aar/pom全部提交到版本管理，然后由持续集成去拉版本库上的.gradle目录，然后生成jcenter提供给内网编译服务器。

#!/bin/bash
#use .gradle/caches/modules-2/files-2.1/ to create jcenter
SHPATH=$(cd "$(dirname "$0")"; pwd)
DIR="${SHPATH}/caches/modules-2/files-2.1/"
DIR_LENGTH=${#DIR}
if [ `uname` = "Darwin" ]; then
#mac will add "/"
	DIR_LENGTH=$((DIR_LENGTH+1))
fi
rm -rf ${SHPATH}/jcenter/*
find ${DIR} -type f | grep -Ev "DS_Store" | while read line
do
	SRC=${line}
	URL=${line:${DIR_LENGTH}}

	ORG=${URL%%/*}
	URL=${URL#*/}

	MODULE=${URL%%/*}
	URL=${URL#*/}

	REVISION=${URL%%/*}
	URL=${URL#*/}

	SHA1=${URL%%/*}
	URL=${URL#*/}

	FILE=${URL}
#echo "ORG=$ORG, MODULE=$MODULE, REVISION=$REVISION, SHA1=$SHA1, FILE=$FILE"

	DST=${SHPATH}/jcenter/${ORG//.//}/${MODULE}/${REVISION}/${FILE}
echo "$DST"
	mkdir -p `dirname ${DST}`
	if [ ! -f ${DST} ]; then
		cp -a ${SRC} ${DST}
fi
done

#!/bin/bash

#use .gradle/caches/modules-2/files-2.1/ to create jcenter

SHPATH=$(cd "$(dirname "$0")"; pwd)

DIR="${SHPATH}/caches/modules-2/files-2.1/"

DIR_LENGTH=${#DIR}

if [ `uname` = "Darwin" ]; then

#mac will add "/"

DIR_LENGTH=$((DIR_LENGTH+1))

rm -rf ${SHPATH}/jcenter/*

find ${DIR} -type f | grep -Ev "DS_Store" | while read line

SRC=${line}

URL=${line:${DIR_LENGTH}}

ORG=${URL%%/*}

URL=${URL#*/}

MODULE=${URL%%/*}

URL=${URL#*/}

REVISION=${URL%%/*}

URL=${URL#*/}

SHA1=${URL%%/*}

URL=${URL#*/}

FILE=${URL}

#echo "ORG=$ORG, MODULE=$MODULE, REVISION=$REVISION, SHA1=$SHA1, FILE=$FILE"

DST=${SHPATH}/jcenter/${ORG//.//}/${MODULE}/${REVISION}/${FILE}

echo "$DST"

mkdir -p `dirname ${DST}`

if [ ! -f ${DST} ]; then

cp -a ${SRC} ${DST}

done

另外，上面提到aar有可能会因为缺失pom导致无法使用，我还写了一个脚本，也是放在.gradle目录下，用于修复aar问题。本地运行时，可以只运行这个脚本，因为它会顺路执行上面的脚本。

以下是fix_aar_cache.sh的内容：

#!/bin/bash
SHPATH=$(cd "$(dirname "$0")"; pwd)

SRC_DIR=${SHPATH}/jcenter
CACHE_DIR="${SHPATH}/caches/modules-2/files-2.1/"
${SHPATH}/mirror.sh > /dev/null

DIR_LENGTH=${#SRC_DIR}
if [ `uname` = "Darwin" ]; then
#mac will add "/"
	DIR_LENGTH=$((DIR_LENGTH+1))
fi
find ${SRC_DIR} -name "*.aar" | while read line
do
	SRC=${line}
	LOCAL_POM=${SRC/.aar/.pom}
if [ -f ${LOCAL_POM} ]; then
continue
fi
echo "$LOCAL_POM not found"

	URL=${line:${DIR_LENGTH}}
	URL=${URL/.aar/.pom}
	REMOTE_POM=http://maven.aliyun.com/nexus/content/repositories/jcenter/${URL}
	REMOTE_POM_SHA1=${REMOTE_POM}.sha1

	SHA1=`wget -q -O- ${REMOTE_POM_SHA1}`
	SHA1=${SHA1:2} #remove additional \r\n
echo $SHA1
#reverse to get it
	FILE=${URL##*/}
	URL=${URL%/*}

	REVISION=${URL##*/}
	URL=${URL%/*}

	MODULE=${URL##*/}
	URL=${URL%/*}

	ORG=${URL}
echo "ORG=$ORG, MODULE=$MODULE, REVISION=$REVISION, FILE=$FILE"
#org /->.
	DST=${CACHE_DIR}/${ORG//\//\.}/${MODULE}/${REVISION}/${SHA1}/${FILE}
echo "$DST"
	mkdir -p `dirname ${DST}`
	if [ ! -f ${DST} ]; then
		wget -O ${DST} ${REMOTE_POM}
fi
done

#!/bin/bash

SHPATH=$(cd "$(dirname "$0")"; pwd)

SRC_DIR=${SHPATH}/jcenter

CACHE_DIR="${SHPATH}/caches/modules-2/files-2.1/"

${SHPATH}/mirror.sh > /dev/null

DIR_LENGTH=${#SRC_DIR}

if [ `uname` = "Darwin" ]; then

#mac will add "/"

DIR_LENGTH=$((DIR_LENGTH+1))

find ${SRC_DIR} -name "*.aar" | while read line

SRC=${line}

LOCAL_POM=${SRC/.aar/.pom}

if [ -f ${LOCAL_POM} ]; then

continue

echo "$LOCAL_POM not found"

URL=${line:${DIR_LENGTH}}

URL=${URL/.aar/.pom}

REMOTE_POM=http://maven.aliyun.com/nexus/content/repositories/jcenter/${URL}

REMOTE_POM_SHA1=${REMOTE_POM}.sha1

SHA1=`wget -q -O- ${REMOTE_POM_SHA1}`

SHA1=${SHA1:2} #remove additional \r\n

echo $SHA1

#reverse to get it

FILE=${URL##*/}

URL=${URL%/*}

REVISION=${URL##*/}

URL=${URL%/*}

MODULE=${URL##*/}

URL=${URL%/*}

ORG=${URL}

echo "ORG=$ORG, MODULE=$MODULE, REVISION=$REVISION, FILE=$FILE"

#org /->.

DST=${CACHE_DIR}/${ORG//\//\.}/${MODULE}/${REVISION}/${SHA1}/${FILE}

echo "$DST"

mkdir -p `dirname ${DST}`

if [ ! -f ${DST} ]; then

wget -O ${DST} ${REMOTE_POM}

done

参考链接

集成华为HMS debug/release 修改包名，取不同包名下的agconnect-services.json 文件

debug/release 修改包名，取不同包名下的agconnect-services.json 文件 V2 解决每次更换包名，都是要手动删除agconnect-services.json文件操作

问题描述

集成华为HMS Core/Push在打多渠道包的时候，我需要区分debug版本，release版本，其中涉及到包名的不同，我使用release编译的时候，发现如下错误信息。这个原因是因为你的agconnect-services文件里面含有一个 package_name 参数，这个参数是需要指定包名的，如果 package_name 填写的报名，和目前你所使用的包名没有对应上就会出现这样的错误

修改过程中遇到的错误信息

* What went wrong:
Execution failed for task ':app:processDebugAGCPlugin'.
> ERROR: Failed to verify AGConnect-Config '/client/package_name', expected: 'com.gxx.fast', but was: 'com.gxx.fast.debug'

* What went wrong:

Execution failed for task ':app:processDebugAGCPlugin'.

> ERROR: Failed to verify AGConnect-Config '/client/package_name', expected: 'com.gxx.fast', but was: 'com.gxx.fast.debug'

不是很完美的解决问题

既然是需要区分包名的，我不如直接copy 2份出来，放到src下面，并新建一个类 pushservices 里面存放 debug/release 的类并存放 agconnect-services.json文件，这样我们想使用哪个版本的，就使用哪个版本的

继续阅读集成华为HMS debug/release 修改包名，取不同包名下的agconnect-services.json 文件

Gradle传递System Property

最近在搭建Jenkins环境，实现Android自动化编译的过程中，由于内网服务器不能访问外网，因此只能配置Robolectric访问内网的服务器。

根据官方文档 Configuring Robolectric，发现如果要更改Robolectric默认的下载服务器链接地址，需要在项目的每个lib库中都配置如下参数，才能实现：

android {
  testOptions {
    unitTests.all {
      systemProperty 'robolectric.dependency.repo.url', 'https://local-mirror/repo'
      systemProperty 'robolectric.dependency.repo.id', 'local'
    }
  }
}

android {

testOptions {

unitTests.all {

systemProperty 'robolectric.dependency.repo.url', 'https://local-mirror/repo'

systemProperty 'robolectric.dependency.repo.id', 'local'

}

但是这样配置有一个问题，就是没办法动态调整链接地址。

而我们使用

$ bash gradlew clean build -Drobolectric.dependency.repo.url=http://127.0.0.1/jcenter

1	$ bash gradlew clean build -Drobolectric.dependency.repo.url=http://127.0.0.1/jcenter

手工指定的参数，并没有在编译的时候生效。

参数丢失的原因是因为测试用例在新的JVM中执行，传入的参数不会自动带给新创建的JVM。

这时需要在Gradle脚本中将读到的值重新设到系统属性里面，才可以被Java程序读到。

android {
    testOptions {
        unitTests.all {
            //命令行下 单元测试可能卡住的问题
            jvmArgs '-noverify'
            //robolectric外部指定下载资源链接的参数，使用 -D 参数指定 bash gradlew clean build -Drobolectric.dependency.repo.url=http://127.0.0.1/jcenter
            systemProperty 'robolectric.dependency.repo.url', System.getProperty("robolectric.dependency.repo.url")
            systemProperty 'robolectric.dependency.repo.id', System.getProperty("robolectric.dependency.repo.id")
        }
    }
}

android {

testOptions {

unitTests.all {

//命令行下单元测试可能卡住的问题

jvmArgs '-noverify'

//robolectric外部指定下载资源链接的参数，使用 -D 参数指定 bash gradlew clean build -Drobolectric.dependency.repo.url=http://127.0.0.1/jcenter

systemProperty 'robolectric.dependency.repo.url', System.getProperty("robolectric.dependency.repo.url")

systemProperty 'robolectric.dependency.repo.id', System.getProperty("robolectric.dependency.repo.id")

}

每个项目的build.gradle中都增加上面的配置之后，就可以保证在外部编译的时候动态指定参数了。

在 Android Studio Chipmunk | 2021.2.1 Patch 1 以及以上的版本，可能会发生如下报错：

URI is not absolute
java.lang.IllegalArgumentException: URI is not absolute
	at java.base/java.net.URL.fromURI(URL.java:692)
	at java.base/java.net.URI.toURL(URI.java:1116)
	at org.robolectric.internal.dependency.MavenArtifactFetcher.getRemoteUrl(MavenArtifactFetcher.java:138)
	at org.robolectric.internal.dependency.MavenArtifactFetcher.fetchToStagingRepository(MavenArtifactFetcher.java:145)
	at org.robolectric.internal.dependency.MavenArtifactFetcher.fetchArtifact(MavenArtifactFetcher.java:65)
	at org.robolectric.internal.dependency.MavenDependencyResolver.lambda$getLocalArtifactUrls$0(MavenDependencyResolver.java:80)
	at org.robolectric.internal.dependency.MavenDependencyResolver.whileLocked(MavenDependencyResolver.java:100)
	at org.robolectric.internal.dependency.MavenDependencyResolver.getLocalArtifactUrls(MavenDependencyResolver.java:75)
	at org.robolectric.internal.dependency.MavenDependencyResolver.getLocalArtifactUrls(MavenDependencyResolver.java:65)
	at org.robolectric.internal.dependency.MavenDependencyResolver.getLocalArtifactUrl(MavenDependencyResolver.java:116)
	at org.robolectric.plugins.LegacyDependencyResolver.getLocalArtifactUrl(LegacyDependencyResolver.java:89)
	at org.robolectric.plugins.DefaultSdkProvider$DefaultSdk.getJarPath(DefaultSdkProvider.java:146)
	at org.robolectric.internal.AndroidSandbox$SdkSandboxClassLoader.<init>(AndroidSandbox.java:102)
	at java.base/jdk.internal.reflect.NativeConstructorAccessorImpl.newInstance0(Native Method)
	at java.base/jdk.internal.reflect.NativeConstructorAccessorImpl.newInstance(NativeConstructorAccessorImpl.java:62)
	at java.base/jdk.internal.reflect.DelegatingConstructorAccessorImpl.newInstance(DelegatingConstructorAccessorImpl.java:45)
	at java.base/java.lang.reflect.Constructor.newInstance(Constructor.java:490)
	at org.robolectric.util.inject.Injector.inject(Injector.java:250)
	at org.robolectric.util.inject.Injector.lambda$memoized$1(Injector.java:232)
	at org.robolectric.util.inject.Injector$MemoizingProvider.get(Injector.java:498)
	at org.robolectric.util.inject.Injector.getInstanceInternal(Injector.java:224)
	at org.robolectric.util.inject.Injector.resolveDependencies(Injector.java:296)
	at org.robolectric.util.inject.Injector.inject(Injector.java:248)
	at org.robolectric.util.inject.Injector.lambda$memoized$1(Injector.java:232)
	at org.robolectric.util.inject.Injector$MemoizingProvider.get(Injector.java:498)
	at org.robolectric.util.inject.Injector.getInstanceInternal(Injector.java:224)
	at org.robolectric.util.inject.Injector.getInstance(Injector.java:208)
	at org.robolectric.util.inject.Injector.access$700(Injector.java:96)
	at org.robolectric.util.inject.Injector$ScopeBuilderProvider.create(Injector.java:564)
	at org.robolectric.util.inject.Injector$ScopeBuilderProvider.lambda$get$0(Injector.java:547)
	at com.sun.proxy.$Proxy19.build(Unknown Source)
	at org.robolectric.internal.SandboxManager.getAndroidSandbox(SandboxManager.java:57)
	at org.robolectric.RobolectricTestRunner.getSandbox(RobolectricTestRunner.java:285)
	at org.robolectric.RobolectricTestRunner.getSandbox(RobolectricTestRunner.java:68)
	at org.robolectric.internal.SandboxTestRunner$2.evaluate(SandboxTestRunner.java:236)
	at org.junit.runners.BlockJUnit4ClassRunner$1.evaluate(BlockJUnit4ClassRunner.java:100)
	at org.junit.runners.ParentRunner.runLeaf(ParentRunner.java:366)
	at org.junit.runners.BlockJUnit4ClassRunner.runChild(BlockJUnit4ClassRunner.java:103)
	at org.junit.runners.BlockJUnit4ClassRunner.runChild(BlockJUnit4ClassRunner.java:63)
	at org.junit.runners.ParentRunner$4.run(ParentRunner.java:331)
	at org.junit.runners.ParentRunner$1.schedule(ParentRunner.java:79)
	at org.junit.runners.ParentRunner.runChildren(ParentRunner.java:329)
	at org.junit.runners.ParentRunner.access$100(ParentRunner.java:66)
	at org.junit.runners.ParentRunner$2.evaluate(ParentRunner.java:293)
	at org.robolectric.internal.SandboxTestRunner$1.evaluate(SandboxTestRunner.java:93)
	at org.junit.runners.ParentRunner.run(ParentRunner.java:413)
	at org.gradle.api.internal.tasks.testing.junit.JUnitTestClassExecutor.runTestClass(JUnitTestClassExecutor.java:110)
	at org.gradle.api.internal.tasks.testing.junit.JUnitTestClassExecutor.execute(JUnitTestClassExecutor.java:58)
	at org.gradle.api.internal.tasks.testing.junit.JUnitTestClassExecutor.execute(JUnitTestClassExecutor.java:38)
	at org.gradle.api.internal.tasks.testing.junit.AbstractJUnitTestClassProcessor.processTestClass(AbstractJUnitTestClassProcessor.java:62)
	at org.gradle.api.internal.tasks.testing.SuiteTestClassProcessor.processTestClass(SuiteTestClassProcessor.java:51)
	at java.base/jdk.internal.reflect.NativeMethodAccessorImpl.invoke0(Native Method)
	at java.base/jdk.internal.reflect.NativeMethodAccessorImpl.invoke(NativeMethodAccessorImpl.java:62)
	at java.base/jdk.internal.reflect.DelegatingMethodAccessorImpl.invoke(DelegatingMethodAccessorImpl.java:43)
	at java.base/java.lang.reflect.Method.invoke(Method.java:566)
	at org.gradle.internal.dispatch.ReflectionDispatch.dispatch(ReflectionDispatch.java:36)
	at org.gradle.internal.dispatch.ReflectionDispatch.dispatch(ReflectionDispatch.java:24)
	at org.gradle.internal.dispatch.ContextClassLoaderDispatch.dispatch(ContextClassLoaderDispatch.java:33)
	at org.gradle.internal.dispatch.ProxyDispatchAdapter$DispatchingInvocationHandler.invoke(ProxyDispatchAdapter.java:94)
	at com.sun.proxy.$Proxy2.processTestClass(Unknown Source)
	at org.gradle.api.internal.tasks.testing.worker.TestWorker$2.run(TestWorker.java:176)
	at org.gradle.api.internal.tasks.testing.worker.TestWorker.executeAndMaintainThreadName(TestWorker.java:129)
	at org.gradle.api.internal.tasks.testing.worker.TestWorker.execute(TestWorker.java:100)
	at org.gradle.api.internal.tasks.testing.worker.TestWorker.execute(TestWorker.java:60)
	at org.gradle.process.internal.worker.child.ActionExecutionWorker.execute(ActionExecutionWorker.java:56)
	at org.gradle.process.internal.worker.child.SystemApplicationClassLoaderWorker.call(SystemApplicationClassLoaderWorker.java:133)
	at org.gradle.process.internal.worker.child.SystemApplicationClassLoaderWorker.call(SystemApplicationClassLoaderWorker.java:71)
	at worker.org.gradle.process.internal.worker.GradleWorkerMain.run(GradleWorkerMain.java:69)
	at worker.org.gradle.process.internal.worker.GradleWorkerMain.main(GradleWorkerMain.java:74)

URI is not absolute

java.lang.IllegalArgumentException: URI is not absolute

at java.base/java.net.URL.fromURI(URL.java:692)

at java.base/java.net.URI.toURL(URI.java:1116)

at org.robolectric.internal.dependency.MavenArtifactFetcher.getRemoteUrl(MavenArtifactFetcher.java:138)

at org.robolectric.internal.dependency.MavenArtifactFetcher.fetchToStagingRepository(MavenArtifactFetcher.java:145)

at org.robolectric.internal.dependency.MavenArtifactFetcher.fetchArtifact(MavenArtifactFetcher.java:65)

at org.robolectric.internal.dependency.MavenDependencyResolver.lambda$getLocalArtifactUrls$0(MavenDependencyResolver.java:80)

at org.robolectric.internal.dependency.MavenDependencyResolver.whileLocked(MavenDependencyResolver.java:100)

at org.robolectric.internal.dependency.MavenDependencyResolver.getLocalArtifactUrls(MavenDependencyResolver.java:75)

at org.robolectric.internal.dependency.MavenDependencyResolver.getLocalArtifactUrls(MavenDependencyResolver.java:65)

at org.robolectric.internal.dependency.MavenDependencyResolver.getLocalArtifactUrl(MavenDependencyResolver.java:116)

at org.robolectric.plugins.LegacyDependencyResolver.getLocalArtifactUrl(LegacyDependencyResolver.java:89)

at org.robolectric.plugins.DefaultSdkProvider$DefaultSdk.getJarPath(DefaultSdkProvider.java:146)

at org.robolectric.internal.AndroidSandbox$SdkSandboxClassLoader.<init>(AndroidSandbox.java:102)

at java.base/jdk.internal.reflect.NativeConstructorAccessorImpl.newInstance0(Native Method)

at java.base/jdk.internal.reflect.NativeConstructorAccessorImpl.newInstance(NativeConstructorAccessorImpl.java:62)

at java.base/jdk.internal.reflect.DelegatingConstructorAccessorImpl.newInstance(DelegatingConstructorAccessorImpl.java:45)

at java.base/java.lang.reflect.Constructor.newInstance(Constructor.java:490)

at org.robolectric.util.inject.Injector.inject(Injector.java:250)

at org.robolectric.util.inject.Injector.lambda$memoized$1(Injector.java:232)

at org.robolectric.util.inject.Injector$MemoizingProvider.get(Injector.java:498)

at org.robolectric.util.inject.Injector.getInstanceInternal(Injector.java:224)

at org.robolectric.util.inject.Injector.resolveDependencies(Injector.java:296)

at org.robolectric.util.inject.Injector.inject(Injector.java:248)

at org.robolectric.util.inject.Injector.lambda$memoized$1(Injector.java:232)

at org.robolectric.util.inject.Injector$MemoizingProvider.get(Injector.java:498)

at org.robolectric.util.inject.Injector.getInstanceInternal(Injector.java:224)

at org.robolectric.util.inject.Injector.getInstance(Injector.java:208)

at org.robolectric.util.inject.Injector.access$700(Injector.java:96)

at org.robolectric.util.inject.Injector$ScopeBuilderProvider.create(Injector.java:564)

at org.robolectric.util.inject.Injector$ScopeBuilderProvider.lambda$get$0(Injector.java:547)

at com.sun.proxy.$Proxy19.build(Unknown Source)

at org.robolectric.internal.SandboxManager.getAndroidSandbox(SandboxManager.java:57)

at org.robolectric.RobolectricTestRunner.getSandbox(RobolectricTestRunner.java:285)

at org.robolectric.RobolectricTestRunner.getSandbox(RobolectricTestRunner.java:68)

at org.robolectric.internal.SandboxTestRunner$2.evaluate(SandboxTestRunner.java:236)

at org.junit.runners.BlockJUnit4ClassRunner$1.evaluate(BlockJUnit4ClassRunner.java:100)

at org.junit.runners.ParentRunner.runLeaf(ParentRunner.java:366)

at org.junit.runners.BlockJUnit4ClassRunner.runChild(BlockJUnit4ClassRunner.java:103)

at org.junit.runners.BlockJUnit4ClassRunner.runChild(BlockJUnit4ClassRunner.java:63)

at org.junit.runners.ParentRunner$4.run(ParentRunner.java:331)

at org.junit.runners.ParentRunner$1.schedule(ParentRunner.java:79)

at org.junit.runners.ParentRunner.runChildren(ParentRunner.java:329)

at org.junit.runners.ParentRunner.access$100(ParentRunner.java:66)

at org.junit.runners.ParentRunner$2.evaluate(ParentRunner.java:293)

at org.robolectric.internal.SandboxTestRunner$1.evaluate(SandboxTestRunner.java:93)

at org.junit.runners.ParentRunner.run(ParentRunner.java:413)

at org.gradle.api.internal.tasks.testing.junit.JUnitTestClassExecutor.runTestClass(JUnitTestClassExecutor.java:110)

at org.gradle.api.internal.tasks.testing.junit.JUnitTestClassExecutor.execute(JUnitTestClassExecutor.java:58)

at org.gradle.api.internal.tasks.testing.junit.JUnitTestClassExecutor.execute(JUnitTestClassExecutor.java:38)

at org.gradle.api.internal.tasks.testing.junit.AbstractJUnitTestClassProcessor.processTestClass(AbstractJUnitTestClassProcessor.java:62)

at org.gradle.api.internal.tasks.testing.SuiteTestClassProcessor.processTestClass(SuiteTestClassProcessor.java:51)

at java.base/jdk.internal.reflect.NativeMethodAccessorImpl.invoke0(Native Method)

at java.base/jdk.internal.reflect.NativeMethodAccessorImpl.invoke(NativeMethodAccessorImpl.java:62)

at java.base/jdk.internal.reflect.DelegatingMethodAccessorImpl.invoke(DelegatingMethodAccessorImpl.java:43)

at java.base/java.lang.reflect.Method.invoke(Method.java:566)

at org.gradle.internal.dispatch.ReflectionDispatch.dispatch(ReflectionDispatch.java:36)

at org.gradle.internal.dispatch.ReflectionDispatch.dispatch(ReflectionDispatch.java:24)

at org.gradle.internal.dispatch.ContextClassLoaderDispatch.dispatch(ContextClassLoaderDispatch.java:33)

at org.gradle.internal.dispatch.ProxyDispatchAdapter$DispatchingInvocationHandler.invoke(ProxyDispatchAdapter.java:94)

at com.sun.proxy.$Proxy2.processTestClass(Unknown Source)

at org.gradle.api.internal.tasks.testing.worker.TestWorker$2.run(TestWorker.java:176)

at org.gradle.api.internal.tasks.testing.worker.TestWorker.executeAndMaintainThreadName(TestWorker.java:129)

at org.gradle.api.internal.tasks.testing.worker.TestWorker.execute(TestWorker.java:100)

at org.gradle.api.internal.tasks.testing.worker.TestWorker.execute(TestWorker.java:60)

at org.gradle.process.internal.worker.child.ActionExecutionWorker.execute(ActionExecutionWorker.java:56)

at org.gradle.process.internal.worker.child.SystemApplicationClassLoaderWorker.call(SystemApplicationClassLoaderWorker.java:133)

at org.gradle.process.internal.worker.child.SystemApplicationClassLoaderWorker.call(SystemApplicationClassLoaderWorker.java:71)

at worker.org.gradle.process.internal.worker.GradleWorkerMain.run(GradleWorkerMain.java:69)

at worker.org.gradle.process.internal.worker.GradleWorkerMain.main(GradleWorkerMain.java:74)

该报错的原因是 Android Studio 没有正确读取我们配置的 robolectric.dependency.repo.url 环境变量，导致无法成功下载，当然也可能是由于高版本不支持 HTTP ，链接地址必须是 HTTPS 导致此问题，这个没有深究。

解决方法是，在命令行执行

$ bash gradlew clean build -Drobolectric.dependency.repo.url=http://127.0.0.1/jcenter

1	$ bash gradlew clean build -Drobolectric.dependency.repo.url=http://127.0.0.1/jcenter

确保在当前用户目录下的 .m2 目录下，成功完成 robolectric 需要的全部文件的下载。这样，执行测试用例的时候，就可以从本地获取依赖文件，而不需要再去服务器上获取。

参考链接

Gradle本站镜像

使用Android Studio开发，最痛苦的其中一项是Maven下载数据缓慢,目前已经可以根据在Ubuntu 14.04 系统中的Apache Tomcat上部署Apache Archiva 2.2.1来使用本站的代理服务器的方式进行提速了。另一个痛苦的事情就是下载Gradle工具包的速度异常缓慢了,不仅慢，而且还容易失败。
目前本网站已经提供了Gradle工具包的下载代理，具体的操作就是把services.gradle.org进行域名污染，指向本站的IP地址121.199.27.227。
Windows下的解决方法为修改C:\Windows\System32\drivers\etc下的hosts文件，里面增加如下内容：

# Copyright (c) 1993-2009 Microsoft Corp.
#
# This is a sample HOSTS file used by Microsoft TCP/IP for Windows.
#
# This file contains the mappings of IP addresses to host names. Each
# entry should be kept on an individual line. The IP address should
# be placed in the first column followed by the corresponding host name.
# The IP address and the host name should be separated by at least one
# space.
#
# Additionally, comments (such as these) may be inserted on individual
# lines or following the machine name denoted by a '#' symbol.
#
# For example:
#
#      102.54.94.97     rhino.acme.com          # source server
#       38.25.63.10     x.acme.com              # x client host

# localhost name resolution is handled within DNS itself.
#	127.0.0.1       localhost
#	::1             localhost
121.199.27.227 services.gradle.org

# This is a sample HOSTS file used by Microsoft TCP/IP for Windows.

# This file contains the mappings of IP addresses to host names. Each

# entry should be kept on an individual line. The IP address should

# be placed in the first column followed by the corresponding host name.

# The IP address and the host name should be separated by at least one

# space.

# Additionally, comments (such as these) may be inserted on individual

# lines or following the machine name denoted by a '#' symbol.

# For example:

# 102.54.94.97 rhino.acme.com # source server

# 38.25.63.10 x.acme.com # x client host

# localhost name resolution is handled within DNS itself.

# 127.0.0.1 localhost

# ::1 localhost

121.199.27.227 services.gradle.org

接着修改Android Studio项目下的gradle\wrapper\gradle-wrapper.properties文件，把其中的

#Tue Aug 16 10:46:15 CST 2016
distributionBase=GRADLE_USER_HOME
distributionPath=wrapper/dists
zipStoreBase=GRADLE_USER_HOME
zipStorePath=wrapper/dists
distributionUrl=https\://services.gradle.org/distributions/gradle-2.14.1-all.zip

#Tue Aug 16 10:46:15 CST 2016

distributionBase=GRADLE_USER_HOME

distributionPath=wrapper/dists

zipStoreBase=GRADLE_USER_HOME

zipStorePath=wrapper/dists

distributionUrl=https\://services.gradle.org/distributions/gradle-2.14.1-all.zip

修改为：

#Tue Aug 16 10:46:15 CST 2016
distributionBase=GRADLE_USER_HOME
distributionPath=wrapper/dists
zipStoreBase=GRADLE_USER_HOME
zipStorePath=wrapper/dists
distributionUrl=http\://services.gradle.org/distributions/gradle-2.14.1-all.zip

#Tue Aug 16 10:46:15 CST 2016

distributionBase=GRADLE_USER_HOME

distributionPath=wrapper/dists

zipStoreBase=GRADLE_USER_HOME

zipStorePath=wrapper/dists

distributionUrl=http\://services.gradle.org/distributions/gradle-2.14.1-all.zip

注意，上面的修改其实主要是把HTTPS修改成了HTTP，原因在于HTTPS无法进行域名污染。

当然，另外一个比较简单的修改方式为，只要修改distributionUrl为本站地址，更加省事：

#Tue Aug 16 10:46:15 CST 2016
distributionBase=GRADLE_USER_HOME
distributionPath=wrapper/dists
zipStoreBase=GRADLE_USER_HOME
zipStorePath=wrapper/dists
distributionUrl=https\://www.mobibrw.com/distributions/gradle-2.14.1-all.zip

#Tue Aug 16 10:46:15 CST 2016

distributionBase=GRADLE_USER_HOME

distributionPath=wrapper/dists

zipStoreBase=GRADLE_USER_HOME

zipStorePath=wrapper/dists

distributionUrl=https\://www.mobibrw.com/distributions/gradle-2.14.1-all.zip

目前本站提供的Gradle工具包版本如下：

gradle-2.10-all.zip.sha256
gradle-2.10-all.zip

gradle-2.14.1-all.zip.sha256
gradle-2.14.1-all.zip

gradle-6.6-all.zip.sha256
gradle-6.6-all.zip

gradle-8.2.1-all.zip

gradle-2.10-all.zip.sha256

gradle-2.10-all.zip

gradle-2.14.1-all.zip.sha256

gradle-2.14.1-all.zip

gradle-6.6-all.zip.sha256

gradle-6.6-all.zip

gradle-8.2.1-all.zip

当前更建议大家使用腾讯的国内镜像 https://mirrors.cloud.tencent.com/gradle/

参考链接

gradle不同版本下载太慢---腾讯做了国内镜像可以直接下载

Android Studio(Gradle)解决库依赖冲突问题

最近在调整代码的时候，出现如下问题：

Cause: com.android.dex.DexException: Multiple dex files define Landroid/support/annotation/AnimRes;
    UNEXPECTED TOP-LEVEL EXCEPTION:
com.android.dex.DexException: Multiple dex files define Landroid/support/annotation/AnimRes;
        at com.android.dx.merge.DexMerger.readSortableTypes(DexMerger.java:579)
        at com.android.dx.merge.DexMerger.getSortedTypes(DexMerger.java:535)
        at com.android.dx.merge.DexMerger.mergeClassDefs(DexMerger.java:517)
        at com.android.dx.merge.DexMerger.mergeDexes(DexMerger.java:164)
        at com.android.dx.merge.DexMerger.merge(DexMerger.java:188)
        at com.android.dx.command.dexer.Main.mergeLibraryDexBuffers(Main.java:504)
        at com.android.dx.command.dexer.Main.runMonoDex(Main.java:334)
        at com.android.dx.command.dexer.Main.run(Main.java:277)
        at com.android.dx.command.dexer.Main.main(Main.java:245)
        at com.android.dx.command.Main.main(Main.java:106)

Cause: com.android.dex.DexException: Multiple dex files define Landroid/support/annotation/AnimRes;

UNEXPECTED TOP-LEVEL EXCEPTION:

com.android.dex.DexException: Multiple dex files define Landroid/support/annotation/AnimRes;

at com.android.dx.merge.DexMerger.readSortableTypes(DexMerger.java:579)

at com.android.dx.merge.DexMerger.getSortedTypes(DexMerger.java:535)

at com.android.dx.merge.DexMerger.mergeClassDefs(DexMerger.java:517)

at com.android.dx.merge.DexMerger.mergeDexes(DexMerger.java:164)

at com.android.dx.merge.DexMerger.merge(DexMerger.java:188)

at com.android.dx.command.dexer.Main.mergeLibraryDexBuffers(Main.java:504)

at com.android.dx.command.dexer.Main.runMonoDex(Main.java:334)

at com.android.dx.command.dexer.Main.run(Main.java:277)

at com.android.dx.command.dexer.Main.main(Main.java:245)

at com.android.dx.command.Main.main(Main.java:106)

网上查询了一下，找到如下的解决方法：

我们常常用gradle.build文件导入依赖库，但是有时候库依赖会发生版本冲突或多个模块依赖同一个库的情况。

这就引出两个问题，如下：

版本冲突时，Gradle会下载多个版本的依赖库吗？
当多个模块依赖同一个库时，每个模块都会去下载该依赖库吗？
为解决这疑问，接下来我们在Android Studio用Gradle举个例子：
gradle.build依赖部分的配置：

dependencies {
    compile 'com.android.support:appcompat-v7:22.2.1'
    compile ('com.android.support:design:22.2.1')
    compile 'com.shamanland:fonticon:0.1.8'
    androidTestCompile 'com.android.support:support-annotations:22.2.1'
    androidTestCompile 'com.android.support.test:runner:0.3'
    androidTestCompile('com.android.support.test.espresso:espresso-core:2.2')
}

dependencies {

compile 'com.android.support:appcompat-v7:22.2.1'

compile ('com.android.support:design:22.2.1')

compile 'com.shamanland:fonticon:0.1.8'

androidTestCompile 'com.android.support:support-annotations:22.2.1'

androidTestCompile 'com.android.support.test:runner:0.3'

androidTestCompile('com.android.support.test.espresso:espresso-core:2.2')

}

在文件目录下或Android Studio的Terminal下敲gradlew -q app:dependencies 命令，便有以下输出：

_debugAndroidTestApk - ## Internal use, do not manually configure ##
+--- com.android.support:support-annotations:22.2.1
+--- com.android.support.test:runner:0.3
|    +--- com.android.support.test:exposed-instrumentation-api-publish:0.3
|    +--- junit:junit:4.12
|    |    \--- org.hamcrest:hamcrest-core:1.3
|    \--- com.android.support:support-annotations:22.2.0 -> 22.2.1
\--- com.android.support.test.espresso:espresso-core:2.2
     +--- com.android.support.test.espresso:espresso-idling-resource:2.2
     +--- com.squareup:javawriter:2.1.1
     +--- javax.inject:javax.inject:1
     +--- org.hamcrest:hamcrest-library:1.3
     |    \--- org.hamcrest:hamcrest-core:1.3
     +--- com.android.support.test:rules:0.3
     |    \--- com.android.support.test:runner:0.3 (*)
     +--- org.hamcrest:hamcrest-integration:1.3
     |    \--- org.hamcrest:hamcrest-library:1.3 (*)
     +--- com.google.code.findbugs:jsr305:2.0.1
     +--- javax.annotation:javax.annotation-api:1.2
     \--- com.android.support.test:runner:0.3 (*)

_debugAndroidTestCompile - ## Internal use, do not manually configure ##
+--- com.android.support:support-annotations:22.2.1
+--- com.android.support.test:runner:0.3
|    +--- com.android.support.test:exposed-instrumentation-api-publish:0.3
|    +--- junit:junit:4.12
|    |    \--- org.hamcrest:hamcrest-core:1.3
|    \--- com.android.support:support-annotations:22.2.0 -> 22.2.1
\--- com.android.support.test.espresso:espresso-core:2.2
     +--- com.android.support.test.espresso:espresso-idling-resource:2.2
     +--- com.squareup:javawriter:2.1.1
     +--- javax.inject:javax.inject:1
     +--- org.hamcrest:hamcrest-library:1.3
     |    \--- org.hamcrest:hamcrest-core:1.3
     +--- com.android.support.test:rules:0.3
     |    \--- com.android.support.test:runner:0.3 (*)
     +--- org.hamcrest:hamcrest-integration:1.3
     |    \--- org.hamcrest:hamcrest-library:1.3 (*)
     +--- com.google.code.findbugs:jsr305:2.0.1
     +--- javax.annotation:javax.annotation-api:1.2
     \--- com.android.support.test:runner:0.3 (*)

_debugApk - ## Internal use, do not manually configure ##
+--- com.android.support:multidex:1.0.1
+--- com.android.support:appcompat-v7:22.2.1
|    \--- com.android.support:support-v4:22.2.1
|         \--- com.android.support:support-annotations:22.2.1
+--- com.android.support:design:22.2.1
|    +--- com.android.support:appcompat-v7:22.2.1 (*)
|    \--- com.android.support:support-v4:22.2.1 (*)
\--- com.shamanland:fonticon:0.1.8

_debugCompile - ## Internal use, do not manually configure ##
+--- com.android.support:multidex:1.0.1
+--- com.android.support:appcompat-v7:22.2.1
|    \--- com.android.support:support-v4:22.2.1
|         \--- com.android.support:support-annotations:22.2.1
+--- com.android.support:design:22.2.1
|    +--- com.android.support:appcompat-v7:22.2.1 (*)
|    \--- com.android.support:support-v4:22.2.1 (*)
\--- com.shamanland:fonticon:0.1.8

_debugUnitTestApk - ## Internal use, do not manually configure ##
No dependencies

_debugUnitTestCompile - ## Internal use, do not manually configure ##
No dependencies

_releaseApk - ## Internal use, do not manually configure ##
+--- com.android.support:multidex:1.0.1
+--- com.android.support:appcompat-v7:22.2.1
|    \--- com.android.support:support-v4:22.2.1
|         \--- com.android.support:support-annotations:22.2.1
+--- com.android.support:design:22.2.1
|    +--- com.android.support:appcompat-v7:22.2.1 (*)
|    \--- com.android.support:support-v4:22.2.1 (*)
\--- com.shamanland:fonticon:0.1.8

_releaseCompile - ## Internal use, do not manually configure ##
+--- com.android.support:multidex:1.0.1
+--- com.android.support:appcompat-v7:22.2.1
|    \--- com.android.support:support-v4:22.2.1
|         \--- com.android.support:support-annotations:22.2.1
+--- com.android.support:design:22.2.1
|    +--- com.android.support:appcompat-v7:22.2.1 (*)
|    \--- com.android.support:support-v4:22.2.1 (*)
\--- com.shamanland:fonticon:0.1.8

_releaseUnitTestApk - ## Internal use, do not manually configure ##
No dependencies

_releaseUnitTestCompile - ## Internal use, do not manually configure ##
No dependencies

androidJacocoAgent - The Jacoco agent to use to get coverage data.
\--- org.jacoco:org.jacoco.agent:0.7.4.201502262128

androidJacocoAnt - The Jacoco ant tasks to use to get execute Gradle tasks.
\--- org.jacoco:org.jacoco.ant:0.7.4.201502262128
     +--- org.jacoco:org.jacoco.core:0.7.4.201502262128
     |    \--- org.ow2.asm:asm-debug-all:5.0.1
     +--- org.jacoco:org.jacoco.report:0.7.4.201502262128
     |    +--- org.jacoco:org.jacoco.core:0.7.4.201502262128 (*)
     |    \--- org.ow2.asm:asm-debug-all:5.0.1
     \--- org.jacoco:org.jacoco.agent:0.7.4.201502262128

androidTestApk - Classpath packaged with the compiled 'androidTest' classes.
No dependencies

androidTestCompile - Classpath for compiling the androidTest sources.
+--- com.android.support:support-annotations:22.2.1
+--- com.android.support.test:runner:0.3
|    +--- com.android.support.test:exposed-instrumentation-api-publish:0.3
|    +--- junit:junit:4.12
|    |    \--- org.hamcrest:hamcrest-core:1.3
|    \--- com.android.support:support-annotations:22.2.0 -> 22.2.1
\--- com.android.support.test.espresso:espresso-core:2.2
     +--- com.android.support.test.espresso:espresso-idling-resource:2.2
     +--- com.squareup:javawriter:2.1.1
     +--- javax.inject:javax.inject:1
     +--- org.hamcrest:hamcrest-library:1.3
     |    \--- org.hamcrest:hamcrest-core:1.3
     +--- com.android.support.test:rules:0.3
     |    \--- com.android.support.test:runner:0.3 (*)
     +--- org.hamcrest:hamcrest-integration:1.3
     |    \--- org.hamcrest:hamcrest-library:1.3 (*)
     +--- com.google.code.findbugs:jsr305:2.0.1
     +--- javax.annotation:javax.annotation-api:1.2
     \--- com.android.support.test:runner:0.3 (*)

androidTestProvided - Classpath for only compiling the androidTest sources.
No dependencies

androidTestWearApp - Link to a wear app to embed for object 'androidTest'.
No dependencies

apk - Classpath packaged with the compiled 'main' classes.
No dependencies

archives - Configuration for archive artifacts.
No dependencies

compile - Classpath for compiling the main sources.
+--- com.android.support:appcompat-v7:22.2.1
|    \--- com.android.support:support-v4:22.2.1
|         \--- com.android.support:support-annotations:22.2.1
+--- com.android.support:design:22.2.1
|    +--- com.android.support:appcompat-v7:22.2.1 (*)
|    \--- com.android.support:support-v4:22.2.1 (*)
\--- com.shamanland:fonticon:0.1.8

100

101

102

103

104

105

106

107

108

109

110

111

112

113

114

115

116

117

118

119

120

121

122

123

124

125

126

127

128

129

130

131

132

133

134

135

136

137

138

139

140

141

142

143

144

145

146

147

148

149

150

_debugAndroidTestApk - ## Internal use, do not manually configure ##

+--- com.android.support:support-annotations:22.2.1

+--- com.android.support.test:runner:0.3

| +--- com.android.support.test:exposed-instrumentation-api-publish:0.3

| +--- junit:junit:4.12

| | \--- org.hamcrest:hamcrest-core:1.3

| \--- com.android.support:support-annotations:22.2.0 -> 22.2.1

\--- com.android.support.test.espresso:espresso-core:2.2

+--- com.android.support.test.espresso:espresso-idling-resource:2.2

+--- com.squareup:javawriter:2.1.1

+--- javax.inject:javax.inject:1

+--- org.hamcrest:hamcrest-library:1.3

| \--- org.hamcrest:hamcrest-core:1.3

+--- com.android.support.test:rules:0.3

| \--- com.android.support.test:runner:0.3 (*)

+--- org.hamcrest:hamcrest-integration:1.3

| \--- org.hamcrest:hamcrest-library:1.3 (*)

+--- com.google.code.findbugs:jsr305:2.0.1

+--- javax.annotation:javax.annotation-api:1.2

\--- com.android.support.test:runner:0.3 (*)

_debugAndroidTestCompile - ## Internal use, do not manually configure ##

+--- com.android.support:support-annotations:22.2.1

+--- com.android.support.test:runner:0.3

| +--- com.android.support.test:exposed-instrumentation-api-publish:0.3

| +--- junit:junit:4.12

| | \--- org.hamcrest:hamcrest-core:1.3

| \--- com.android.support:support-annotations:22.2.0 -> 22.2.1

\--- com.android.support.test.espresso:espresso-core:2.2

+--- com.android.support.test.espresso:espresso-idling-resource:2.2

+--- com.squareup:javawriter:2.1.1

+--- javax.inject:javax.inject:1

+--- org.hamcrest:hamcrest-library:1.3

| \--- org.hamcrest:hamcrest-core:1.3

+--- com.android.support.test:rules:0.3

| \--- com.android.support.test:runner:0.3 (*)

+--- org.hamcrest:hamcrest-integration:1.3

| \--- org.hamcrest:hamcrest-library:1.3 (*)

+--- com.google.code.findbugs:jsr305:2.0.1

+--- javax.annotation:javax.annotation-api:1.2

\--- com.android.support.test:runner:0.3 (*)

_debugApk - ## Internal use, do not manually configure ##

+--- com.android.support:multidex:1.0.1

+--- com.android.support:appcompat-v7:22.2.1

| \--- com.android.support:support-v4:22.2.1

| \--- com.android.support:support-annotations:22.2.1

+--- com.android.support:design:22.2.1

| +--- com.android.support:appcompat-v7:22.2.1 (*)

| \--- com.android.support:support-v4:22.2.1 (*)

\--- com.shamanland:fonticon:0.1.8

_debugCompile - ## Internal use, do not manually configure ##

+--- com.android.support:multidex:1.0.1

+--- com.android.support:appcompat-v7:22.2.1

| \--- com.android.support:support-v4:22.2.1

| \--- com.android.support:support-annotations:22.2.1

+--- com.android.support:design:22.2.1

| +--- com.android.support:appcompat-v7:22.2.1 (*)

| \--- com.android.support:support-v4:22.2.1 (*)

\--- com.shamanland:fonticon:0.1.8

_debugUnitTestApk - ## Internal use, do not manually configure ##

No dependencies

_debugUnitTestCompile - ## Internal use, do not manually configure ##

No dependencies

_releaseApk - ## Internal use, do not manually configure ##

+--- com.android.support:multidex:1.0.1

+--- com.android.support:appcompat-v7:22.2.1

| \--- com.android.support:support-v4:22.2.1

| \--- com.android.support:support-annotations:22.2.1

+--- com.android.support:design:22.2.1

| +--- com.android.support:appcompat-v7:22.2.1 (*)

| \--- com.android.support:support-v4:22.2.1 (*)

\--- com.shamanland:fonticon:0.1.8

_releaseCompile - ## Internal use, do not manually configure ##

+--- com.android.support:multidex:1.0.1

+--- com.android.support:appcompat-v7:22.2.1

| \--- com.android.support:support-v4:22.2.1

| \--- com.android.support:support-annotations:22.2.1

+--- com.android.support:design:22.2.1

| +--- com.android.support:appcompat-v7:22.2.1 (*)

| \--- com.android.support:support-v4:22.2.1 (*)

\--- com.shamanland:fonticon:0.1.8

_releaseUnitTestApk - ## Internal use, do not manually configure ##

No dependencies

_releaseUnitTestCompile - ## Internal use, do not manually configure ##

No dependencies

androidJacocoAgent - The Jacoco agent to use to get coverage data.

\--- org.jacoco:org.jacoco.agent:0.7.4.201502262128

androidJacocoAnt - The Jacoco ant tasks to use to get execute Gradle tasks.

\--- org.jacoco:org.jacoco.ant:0.7.4.201502262128

+--- org.jacoco:org.jacoco.core:0.7.4.201502262128

| \--- org.ow2.asm:asm-debug-all:5.0.1

+--- org.jacoco:org.jacoco.report:0.7.4.201502262128

| +--- org.jacoco:org.jacoco.core:0.7.4.201502262128 (*)

| \--- org.ow2.asm:asm-debug-all:5.0.1

\--- org.jacoco:org.jacoco.agent:0.7.4.201502262128

androidTestApk - Classpath packaged with the compiled 'androidTest' classes.

No dependencies

androidTestCompile - Classpath for compiling the androidTest sources.

+--- com.android.support:support-annotations:22.2.1

+--- com.android.support.test:runner:0.3

| +--- com.android.support.test:exposed-instrumentation-api-publish:0.3

| +--- junit:junit:4.12

| | \--- org.hamcrest:hamcrest-core:1.3

| \--- com.android.support:support-annotations:22.2.0 -> 22.2.1

\--- com.android.support.test.espresso:espresso-core:2.2

+--- com.android.support.test.espresso:espresso-idling-resource:2.2

+--- com.squareup:javawriter:2.1.1

+--- javax.inject:javax.inject:1

+--- org.hamcrest:hamcrest-library:1.3

| \--- org.hamcrest:hamcrest-core:1.3

+--- com.android.support.test:rules:0.3

| \--- com.android.support.test:runner:0.3 (*)

+--- org.hamcrest:hamcrest-integration:1.3

| \--- org.hamcrest:hamcrest-library:1.3 (*)

+--- com.google.code.findbugs:jsr305:2.0.1

+--- javax.annotation:javax.annotation-api:1.2

\--- com.android.support.test:runner:0.3 (*)

androidTestProvided - Classpath for only compiling the androidTest sources.

No dependencies

androidTestWearApp - Link to a wear app to embed for object 'androidTest'.

No dependencies

apk - Classpath packaged with the compiled 'main' classes.

No dependencies

archives - Configuration for archive artifacts.

No dependencies

compile - Classpath for compiling the main sources.

+--- com.android.support:appcompat-v7:22.2.1

| \--- com.android.support:support-v4:22.2.1

| \--- com.android.support:support-annotations:22.2.1

+--- com.android.support:design:22.2.1

| +--- com.android.support:appcompat-v7:22.2.1 (*)

| \--- com.android.support:support-v4:22.2.1 (*)

\--- com.shamanland:fonticon:0.1.8

可以看出:com.android.support.test:runner:0.3 这个模块原本是依赖于com.android.support:support-annotations22.2.0版本，但由于你又在gradle.build中加了这行androidTestCompile 'com.android.support:support-annotations:22.2.1' 故gradle就会下载com.android.support:support-annotations22.2.1版本，而不会去下载com.android.support:support-annotations22.2.0版本，因此com.android.support.test:runner:0.3 就会被强转变依赖于com.android.support:support-annotations22.2.1版本
第二个问题，我还是利用上面gradle命令行打出的信息来看看：

debugApk - ## Internal use, do not manually configure ##
+--- com.android.support:multidex:1.0.1
+--- com.android.support:appcompat-v7:22.2.1
|    \--- com.android.support:support-v4:22.2.1
|         \--- com.android.support:support-annotations:22.2.1
+--- com.android.support:design:22.2.1
|    +--- com.android.support:appcompat-v7:22.2.1 (*)
|    \--- com.android.support:support-v4:22.2.1 (*)
\--- com.shamanland:fonticon:0.1.8

debugApk - ## Internal use, do not manually configure ##

+--- com.android.support:multidex:1.0.1

+--- com.android.support:appcompat-v7:22.2.1

| \--- com.android.support:support-v4:22.2.1

| \--- com.android.support:support-annotations:22.2.1

+--- com.android.support:design:22.2.1

| +--- com.android.support:appcompat-v7:22.2.1 (*)

| \--- com.android.support:support-v4:22.2.1 (*)

\--- com.shamanland:fonticon:0.1.8

仔细看上面的依赖，com.android.support:appcompat-v7:22.2.1 和com.android.support:design:22.2.1，有共同依赖一个com.android.support:support-v4:22.2.1库，且com.android.support:design:22.2.1 依赖于com.android.support:appcompat-v7:22.2.1，但从打印出的信息可以看出com.android.support:design:22.2.1 依赖两个库的信息被打了星号标记，这标记意思是忽略这两个依赖的意思，也就是说不去下载这两个库。
从上面的两个例子来看，gradle对于需要多个版本的依赖库来说，一般只会下载你配置导入那个版本，如果没有手动导入，那就会下载所有模块依赖的最新版本那个库，面对多个模块依赖同一个库，每个模块不都会去下载该依赖库，而是下载一个该依赖库，共享给多个模块。
修改配置文件为：

dependencies {
    compile 'com.android.support:appcompat-v7:22.2.1'
    compile ('com.android.support:design:22.2.1')
            {
                exclude group: 'com.android.support'
            }
    compile 'com.shamanland:fonticon:0.1.8'
    androidTestCompile 'com.android.support:support-annotations:22.2.1'
    androidTestCompile 'com.android.support.test:runner:0.3'
    androidTestCompile('com.android.support.test.espresso:espresso-core:2.2')
            {
                exclude  group:'com.android.support.test'
            }
}

dependencies {

compile 'com.android.support:appcompat-v7:22.2.1'

compile ('com.android.support:design:22.2.1')

{

exclude group: 'com.android.support'

}

compile 'com.shamanland:fonticon:0.1.8'

androidTestCompile 'com.android.support:support-annotations:22.2.1'

androidTestCompile 'com.android.support.test:runner:0.3'

androidTestCompile('com.android.support.test.espresso:espresso-core:2.2')

{

exclude group:'com.android.support.test'

}

打印信息：

$ gradlew -q app:dependencies

------------------------------------------------------------
Project :app
------------------------------------------------------------

_debugAndroidTestApk - ## Internal use, do not manually configure ##
+--- com.android.support:support-annotations:22.2.1
+--- com.android.support.test:runner:0.3
|    +--- com.android.support.test:exposed-instrumentation-api-publish:0.3
|    +--- junit:junit:4.12
|    |    \--- org.hamcrest:hamcrest-core:1.3
|    \--- com.android.support:support-annotations:22.2.0 -> 22.2.1
\--- com.android.support.test.espresso:espresso-core:2.2
     +--- com.android.support.test.espresso:espresso-idling-resource:2.2
     +--- com.squareup:javawriter:2.1.1
     +--- javax.inject:javax.inject:1
     +--- org.hamcrest:hamcrest-library:1.3
     |    \--- org.hamcrest:hamcrest-core:1.3
     +--- org.hamcrest:hamcrest-integration:1.3
     |    \--- org.hamcrest:hamcrest-library:1.3 (*)
     +--- com.google.code.findbugs:jsr305:2.0.1
     \--- javax.annotation:javax.annotation-api:1.2

_debugAndroidTestCompile - ## Internal use, do not manually configure ##
+--- com.android.support:support-annotations:22.2.1
+--- com.android.support.test:runner:0.3
|    +--- com.android.support.test:exposed-instrumentation-api-publish:0.3
|    +--- junit:junit:4.12
|    |    \--- org.hamcrest:hamcrest-core:1.3
|    \--- com.android.support:support-annotations:22.2.0 -> 22.2.1
\--- com.android.support.test.espresso:espresso-core:2.2
     +--- com.android.support.test.espresso:espresso-idling-resource:2.2
     +--- com.squareup:javawriter:2.1.1
     +--- javax.inject:javax.inject:1
     +--- org.hamcrest:hamcrest-library:1.3
     |    \--- org.hamcrest:hamcrest-core:1.3
     +--- org.hamcrest:hamcrest-integration:1.3
     |    \--- org.hamcrest:hamcrest-library:1.3 (*)
     +--- com.google.code.findbugs:jsr305:2.0.1
     \--- javax.annotation:javax.annotation-api:1.2

_debugApk - ## Internal use, do not manually configure ##
+--- com.android.support:multidex:1.0.1
+--- com.android.support:appcompat-v7:22.2.1
|    \--- com.android.support:support-v4:22.2.1
|         \--- com.android.support:support-annotations:22.2.1
+--- com.android.support:design:22.2.1
\--- com.shamanland:fonticon:0.1.8

_debugCompile - ## Internal use, do not manually configure ##
+--- com.android.support:multidex:1.0.1
+--- com.android.support:appcompat-v7:22.2.1
|    \--- com.android.support:support-v4:22.2.1
|         \--- com.android.support:support-annotations:22.2.1
+--- com.android.support:design:22.2.1
\--- com.shamanland:fonticon:0.1.8

_debugUnitTestApk - ## Internal use, do not manually configure ##
No dependencies

_debugUnitTestCompile - ## Internal use, do not manually configure ##
No dependencies

_releaseApk - ## Internal use, do not manually configure ##
+--- com.android.support:multidex:1.0.1
+--- com.android.support:appcompat-v7:22.2.1
|    \--- com.android.support:support-v4:22.2.1
|         \--- com.android.support:support-annotations:22.2.1
+--- com.android.support:design:22.2.1
\--- com.shamanland:fonticon:0.1.8

_releaseCompile - ## Internal use, do not manually configure ##
+--- com.android.support:multidex:1.0.1
+--- com.android.support:appcompat-v7:22.2.1
|    \--- com.android.support:support-v4:22.2.1
|         \--- com.android.support:support-annotations:22.2.1
+--- com.android.support:design:22.2.1
\--- com.shamanland:fonticon:0.1.8

_releaseUnitTestApk - ## Internal use, do not manually configure ##
No dependencies

_releaseUnitTestCompile - ## Internal use, do not manually configure ##
No dependencies

androidJacocoAgent - The Jacoco agent to use to get coverage data.
\--- org.jacoco:org.jacoco.agent:0.7.4.201502262128

androidJacocoAnt - The Jacoco ant tasks to use to get execute Gradle tasks.
\--- org.jacoco:org.jacoco.ant:0.7.4.201502262128
     +--- org.jacoco:org.jacoco.core:0.7.4.201502262128
     |    \--- org.ow2.asm:asm-debug-all:5.0.1
     +--- org.jacoco:org.jacoco.report:0.7.4.201502262128
     |    +--- org.jacoco:org.jacoco.core:0.7.4.201502262128 (*)
     |    \--- org.ow2.asm:asm-debug-all:5.0.1
     \--- org.jacoco:org.jacoco.agent:0.7.4.201502262128

androidTestApk - Classpath packaged with the compiled 'androidTest' classes.
No dependencies

androidTestCompile - Classpath for compiling the androidTest sources.
+--- com.android.support:support-annotations:22.2.1
+--- com.android.support.test:runner:0.3
|    +--- com.android.support.test:exposed-instrumentation-api-publish:0.3
|    +--- junit:junit:4.12
|    |    \--- org.hamcrest:hamcrest-core:1.3
|    \--- com.android.support:support-annotations:22.2.0 -> 22.2.1
\--- com.android.support.test.espresso:espresso-core:2.2
     +--- com.android.support.test.espresso:espresso-idling-resource:2.2
     +--- com.squareup:javawriter:2.1.1
     +--- javax.inject:javax.inject:1
     +--- org.hamcrest:hamcrest-library:1.3
     |    \--- org.hamcrest:hamcrest-core:1.3
     +--- org.hamcrest:hamcrest-integration:1.3
     |    \--- org.hamcrest:hamcrest-library:1.3 (*)
     +--- com.google.code.findbugs:jsr305:2.0.1
     \--- javax.annotation:javax.annotation-api:1.2

androidTestProvided - Classpath for only compiling the androidTest sources.
No dependencies

androidTestWearApp - Link to a wear app to embed for object 'androidTest'.
No dependencies

apk - Classpath packaged with the compiled 'main' classes.
No dependencies

archives - Configuration for archive artifacts.
No dependencies

compile - Classpath for compiling the main sources.
+--- com.android.support:appcompat-v7:22.2.1
|    \--- com.android.support:support-v4:22.2.1
|         \--- com.android.support:support-annotations:22.2.1
+--- com.android.support:design:22.2.1
\--- com.shamanland:fonticon:0.1.8

100

101

102

103

104

105

106

107

108

109

110

111

112

113

114

115

116

117

118

119

120

121

122

123

124

125

126

127

128

129

130

131

132

133

134

135

136

137

$ gradlew -q app:dependencies

------------------------------------------------------------

Project :app

------------------------------------------------------------

_debugAndroidTestApk - ## Internal use, do not manually configure ##

+--- com.android.support:support-annotations:22.2.1

+--- com.android.support.test:runner:0.3

| +--- com.android.support.test:exposed-instrumentation-api-publish:0.3

| +--- junit:junit:4.12

| | \--- org.hamcrest:hamcrest-core:1.3

| \--- com.android.support:support-annotations:22.2.0 -> 22.2.1

\--- com.android.support.test.espresso:espresso-core:2.2

+--- com.android.support.test.espresso:espresso-idling-resource:2.2

+--- com.squareup:javawriter:2.1.1

+--- javax.inject:javax.inject:1

+--- org.hamcrest:hamcrest-library:1.3

| \--- org.hamcrest:hamcrest-core:1.3

+--- org.hamcrest:hamcrest-integration:1.3

| \--- org.hamcrest:hamcrest-library:1.3 (*)

+--- com.google.code.findbugs:jsr305:2.0.1

\--- javax.annotation:javax.annotation-api:1.2

_debugAndroidTestCompile - ## Internal use, do not manually configure ##

+--- com.android.support:support-annotations:22.2.1

+--- com.android.support.test:runner:0.3

| +--- com.android.support.test:exposed-instrumentation-api-publish:0.3

| +--- junit:junit:4.12

| | \--- org.hamcrest:hamcrest-core:1.3

| \--- com.android.support:support-annotations:22.2.0 -> 22.2.1

\--- com.android.support.test.espresso:espresso-core:2.2

+--- com.android.support.test.espresso:espresso-idling-resource:2.2

+--- com.squareup:javawriter:2.1.1

+--- javax.inject:javax.inject:1

+--- org.hamcrest:hamcrest-library:1.3

| \--- org.hamcrest:hamcrest-core:1.3

+--- org.hamcrest:hamcrest-integration:1.3

| \--- org.hamcrest:hamcrest-library:1.3 (*)

+--- com.google.code.findbugs:jsr305:2.0.1

\--- javax.annotation:javax.annotation-api:1.2

_debugApk - ## Internal use, do not manually configure ##

+--- com.android.support:multidex:1.0.1

+--- com.android.support:appcompat-v7:22.2.1

| \--- com.android.support:support-v4:22.2.1

| \--- com.android.support:support-annotations:22.2.1

+--- com.android.support:design:22.2.1

\--- com.shamanland:fonticon:0.1.8

_debugCompile - ## Internal use, do not manually configure ##

+--- com.android.support:multidex:1.0.1

+--- com.android.support:appcompat-v7:22.2.1

| \--- com.android.support:support-v4:22.2.1

| \--- com.android.support:support-annotations:22.2.1

+--- com.android.support:design:22.2.1

\--- com.shamanland:fonticon:0.1.8

_debugUnitTestApk - ## Internal use, do not manually configure ##

No dependencies

_debugUnitTestCompile - ## Internal use, do not manually configure ##

No dependencies

_releaseApk - ## Internal use, do not manually configure ##

+--- com.android.support:multidex:1.0.1

+--- com.android.support:appcompat-v7:22.2.1

| \--- com.android.support:support-v4:22.2.1

| \--- com.android.support:support-annotations:22.2.1

+--- com.android.support:design:22.2.1

\--- com.shamanland:fonticon:0.1.8

_releaseCompile - ## Internal use, do not manually configure ##

+--- com.android.support:multidex:1.0.1

+--- com.android.support:appcompat-v7:22.2.1

| \--- com.android.support:support-v4:22.2.1

| \--- com.android.support:support-annotations:22.2.1

+--- com.android.support:design:22.2.1

\--- com.shamanland:fonticon:0.1.8

_releaseUnitTestApk - ## Internal use, do not manually configure ##

No dependencies

_releaseUnitTestCompile - ## Internal use, do not manually configure ##

No dependencies

androidJacocoAgent - The Jacoco agent to use to get coverage data.

\--- org.jacoco:org.jacoco.agent:0.7.4.201502262128

androidJacocoAnt - The Jacoco ant tasks to use to get execute Gradle tasks.

\--- org.jacoco:org.jacoco.ant:0.7.4.201502262128

+--- org.jacoco:org.jacoco.core:0.7.4.201502262128

| \--- org.ow2.asm:asm-debug-all:5.0.1

+--- org.jacoco:org.jacoco.report:0.7.4.201502262128

| +--- org.jacoco:org.jacoco.core:0.7.4.201502262128 (*)

| \--- org.ow2.asm:asm-debug-all:5.0.1

\--- org.jacoco:org.jacoco.agent:0.7.4.201502262128

androidTestApk - Classpath packaged with the compiled 'androidTest' classes.

No dependencies

androidTestCompile - Classpath for compiling the androidTest sources.

+--- com.android.support:support-annotations:22.2.1

+--- com.android.support.test:runner:0.3

| +--- com.android.support.test:exposed-instrumentation-api-publish:0.3

| +--- junit:junit:4.12

| | \--- org.hamcrest:hamcrest-core:1.3

| \--- com.android.support:support-annotations:22.2.0 -> 22.2.1

\--- com.android.support.test.espresso:espresso-core:2.2

+--- com.android.support.test.espresso:espresso-idling-resource:2.2

+--- com.squareup:javawriter:2.1.1

+--- javax.inject:javax.inject:1

+--- org.hamcrest:hamcrest-library:1.3

| \--- org.hamcrest:hamcrest-core:1.3

+--- org.hamcrest:hamcrest-integration:1.3

| \--- org.hamcrest:hamcrest-library:1.3 (*)

+--- com.google.code.findbugs:jsr305:2.0.1

\--- javax.annotation:javax.annotation-api:1.2

androidTestProvided - Classpath for only compiling the androidTest sources.

No dependencies

androidTestWearApp - Link to a wear app to embed for object 'androidTest'.

No dependencies

apk - Classpath packaged with the compiled 'main' classes.

No dependencies

archives - Configuration for archive artifacts.

No dependencies

compile - Classpath for compiling the main sources.

+--- com.android.support:appcompat-v7:22.2.1

| \--- com.android.support:support-v4:22.2.1

| \--- com.android.support:support-annotations:22.2.1

+--- com.android.support:design:22.2.1

\--- com.shamanland:fonticon:0.1.8

比较上面两种配置compile信息部分，后面一种配置的 com.android.support:design:22.2.1 就没有输出两个打星号的依赖库信息了。
因此遇到这两种情况是，是gradle能自动帮我们解决掉了这两种情况，对于如何使用gralde命令行查看库依赖(depends)请看官方文档

参考链接

gradle 管理依赖库两个问题

Windows下搭建基于Jenkins+Git+Gradle的Android持续集成

下载`Jenkins`

官网下载，如果官网下载存在问题，也可以在本站下载Jenkins。

下载`Gradle`

目前Android Studio支持的是Gradle 2.8版本,因此下载2.8版本的即可。Gradle 2.8，也可以本站下载。

安装Tomcat

官方主页Apache Tomcat。Windows下面建议下载32-bit/64-bit Windows Service Installer版本。
DownloadTomcat9

安装`Jenkins`

将下载的jenkins.war包直接放到tomcat下的webapps目录，启动tomcat,在浏览器输入:http://127.0.0.1:8080/jenkins

安装`Git plugin`,`Gradle plugin`,`Android Lint Plugin`插件

点击Jenkins首页的"Manage Jenkins"链接，如下图：
ManageJenkins

进入设置，点击"Manage Plugins"，添加Git plugin,Gradle plugin,Android Lint Plugin

ManagePlugins 在打开的页面中，搜索并且安装插件

PluginManagerInstall

系统配置

返回首页，点击" Manage Plugins"，然后进入页面中选择Configure System,配置JDK,Gradle,Git的选项。

JenkinsConfigure
设置JDK
SettingJava

SettingJavaManual

新建项目

首页点击"创建一个新任务",如下图：
NewJenkinsJobs
在接下来的页面中,输入工程的名字，并且选择"Freestyle project"

NewJobsCreateSelect
设置Git中源代码的路径，如果是使用SSH证书认证的登陆，则在Credentials中进行配置,如下图：

JenkinsJobAndroidConfigureGitNew

接下来配置触发构建的条件，目前我们设置为每天晚上3点，注意里面输入的是H 3 * * *,每个字符之间都有一个英文的空格。

JenkinsJobAndroidConfigureTrigger

接下来，配置Gralde的编译，在构建项目中选择"Invoke Gradle Script",如下图：
InvokeGradleScript
在选项的Tasks栏目中输入clean build --stacktrace --debug,如下图：

InvokeGradleScriptTasks
接下来，配置构建后操作,一般增加Publish Android Lint results,Archive the artifacts这两项即可，具体的配置参考下图：

InvokeGradleScriptTasksAfterBuild

构建项目

BuildNow

检验构建结果

构建完成以后检查一下，如果在：

当前用户目录\.jenkins\jobs\Android\workspace\app\build\outputs\apk\

1	当前用户目录\.jenkins\jobs\Android\workspace\app\build\outputs\apk\

下面成功生成了APK文件，则说明配置是成功的。

参考链接

基于Jenkins+git+gradle的android持续集成，jenkinsgradle

Mac Gradle 编译报告Failure initializing default system SSL context

Mac 10.9 版本下使用Gradle 编译 Android 项目，报告错误

Failure initializing default system SSL context

1	Failure initializing default system SSL context

使用 -debug 参数，得到的详细输出如下

2:34:15.273 [ERROR] [org.gradle.BuildExceptionReporter]     at org.gradle.launcher.bootstrap.ProcessBootstrap.runNoExit(ProcessBootstrap.java:50)
22:34:15.278 [ERROR] [org.gradle.BuildExceptionReporter]     at org.gradle.launcher.bootstrap.ProcessBootstrap.run(ProcessBootstrap.java:32)
22:34:15.279 [ERROR] [org.gradle.BuildExceptionReporter]     at org.gradle.launcher.GradleMain.main(GradleMain.java:26)
22:34:15.281 [ERROR] [org.gradle.BuildExceptionReporter] Caused by: java.io.FileNotFoundException: /System/Library/Frameworks/JavaVM.framework/Versions/1.5.0/Home/lib/security/cacerts (No such file or directory)
22:34:15.284 [ERROR] [org.gradle.BuildExceptionReporter]     at java.io.FileInputStream.open(Native Method)
22:34:15.285 [ERROR] [org.gradle.BuildExceptionReporter]     at java.io.FileInputStream.<init>(FileInputStream.java:106)
22:34:15.286 [ERROR] [org.gradle.BuildExceptionReporter]     at org.apache.http.conn.ssl.SSLSocketFactory.createSystemSSLContext(SSLSocketFactory.java:299)
22:34:15.288 [ERROR] [org.gradle.BuildExceptionReporter]     at org.apache.http.conn.ssl.SSLSocketFactory.createSystemSSLContext(SSLSocketFactory.java:366)
22:34:15.289 [ERROR] [org.gradle.BuildExceptionReporter]     ... 147 more

2:34:15.273 [ERROR] [org.gradle.BuildExceptionReporter] at org.gradle.launcher.bootstrap.ProcessBootstrap.runNoExit(ProcessBootstrap.java:50)

22:34:15.278 [ERROR] [org.gradle.BuildExceptionReporter] at org.gradle.launcher.bootstrap.ProcessBootstrap.run(ProcessBootstrap.java:32)

22:34:15.279 [ERROR] [org.gradle.BuildExceptionReporter] at org.gradle.launcher.GradleMain.main(GradleMain.java:26)

22:34:15.281 [ERROR] [org.gradle.BuildExceptionReporter] Caused by: java.io.FileNotFoundException: /System/Library/Frameworks/JavaVM.framework/Versions/1.5.0/Home/lib/security/cacerts (No such file or directory)

22:34:15.284 [ERROR] [org.gradle.BuildExceptionReporter] at java.io.FileInputStream.open(Native Method)

22:34:15.285 [ERROR] [org.gradle.BuildExceptionReporter] at java.io.FileInputStream.<init>(FileInputStream.java:106)

22:34:15.286 [ERROR] [org.gradle.BuildExceptionReporter] at org.apache.http.conn.ssl.SSLSocketFactory.createSystemSSLContext(SSLSocketFactory.java:299)

22:34:15.288 [ERROR] [org.gradle.BuildExceptionReporter] at org.apache.http.conn.ssl.SSLSocketFactory.createSystemSSLContext(SSLSocketFactory.java:366)

22:34:15.289 [ERROR] [org.gradle.BuildExceptionReporter] ... 147 more

可以看到，异常信息为

22:34:15.281 [ERROR] [org.gradle.BuildExceptionReporter] Caused by: java.io.FileNotFoundException: /System/Library/Frameworks/JavaVM.framework/Versions/1.5.0/Home/lib/security/cacerts (No such file or directory)

1	22:34:15.281 [ERROR] [org.gradle.BuildExceptionReporter] Caused by: java.io.FileNotFoundException: /System/Library/Frameworks/JavaVM.framework/Versions/1.5.0/Home/lib/security/cacerts (No such file or directory)

到具体的目录下面去看，这个文件果然是不存在的，有些版本链接到了一个不存在的目录，这种情况一般是经历过系统升级，往往会造成这个现象，另外，就是系统安装的Java 是Apple 提供的 Java 版本，而不是 Orcale 官网下载的独立版本。

解决方法是可以到Orcale 官网下载最新版本的 Java ，安装替换即可解决问题。

使用 Homebrew 安装指定版本的软件

在命令行下使用

$ brew install FORMULANAME

1	$ brew install FORMULANAME

就可以安装 FORMULANAME 对应的工具，它会处理好依赖关系，非常方便。默认情况下，安装最新版本。但是现在在使用 Gradle 的时候，最新版本的 Gradle 是1.10，但是编译Android 的项目失败，只能降级成 1.9 版本的才行，解决方法如下

1.查看 brew 支持哪些版本的 gradle

$ sudo brew versions gradle
Warning: brew-versions is unsupported and may be removed soon.
Please use the homebrew-versions tap instead:
  https://github.com/Homebrew/homebrew-versions
1.10     git checkout 2b10422 Library/Formula/gradle.rb
1.9      git checkout 5bab5e9 Library/Formula/gradle.rb
1.8      git checkout 9214e60 Library/Formula/gradle.rb
1.7      git checkout f826cc9 Library/Formula/gradle.rb
1.6      git checkout fff7c0b Library/Formula/gradle.rb
1.5      git checkout 57931e0 Library/Formula/gradle.rb
1.4      git checkout 0b7303a Library/Formula/gradle.rb
1.3      git checkout c259bda Library/Formula/gradle.rb
1.2      git checkout 9b7d294 Library/Formula/gradle.rb
1.1      git checkout 7941972 Library/Formula/gradle.rb
1.0      git checkout dff67fb Library/Formula/gradle.rb
1.0-rc-3 git checkout 5f9e348 Library/Formula/gradle.rb
1.0-rc-2 git checkout f72e33f Library/Formula/gradle.rb
1.0-rc-1 git checkout e2438cf Library/Formula/gradle.rb
1.0-milestone-9 git checkout c27c667 Library/Formula/gradle.rb
1.0-milestone-8a git checkout 69eb948 Library/Formula/gradle.rb
1.0-milestone-8 git checkout 34da975 Library/Formula/gradle.rb
1.0-milestone-7 git checkout 6a8c437 Library/Formula/gradle.rb
1.0-milestone-6 git checkout dae625d Library/Formula/gradle.rb
1.0-milestone-5 git checkout baff305 Library/Formula/gradle.rb
1.0-milestone-3 git checkout d9f2e06 Library/Formula/gradle.rb
1.0-milestone-4 git checkout 4b1230c Library/Formula/gradle.rb
1.0-milestone-2 git checkout 6801464 Library/Formula/gradle.rb
1.0-milestone-1 git checkout 0476235 Library/Formula/gradle.rb
0.9.2    git checkout 38b9338 Library/Formula/gradle.rb
0.9.1    git checkout f986d7d Library/Formula/gradle.rb
0.9      git checkout 45e09d7 Library/Formula/gradle.rb
0.8      git checkout e6f608f Library/Formula/gradle.rb

$ sudo brew versions gradle

Warning: brew-versions is unsupported and may be removed soon.

Please use the homebrew-versions tap instead:

https://github.com/Homebrew/homebrew-versions

1.10 git checkout 2b10422 Library/Formula/gradle.rb

1.9 git checkout 5bab5e9 Library/Formula/gradle.rb

1.8 git checkout 9214e60 Library/Formula/gradle.rb

1.7 git checkout f826cc9 Library/Formula/gradle.rb

1.6 git checkout fff7c0b Library/Formula/gradle.rb

1.5 git checkout 57931e0 Library/Formula/gradle.rb

1.4 git checkout 0b7303a Library/Formula/gradle.rb

1.3 git checkout c259bda Library/Formula/gradle.rb

1.2 git checkout 9b7d294 Library/Formula/gradle.rb

1.1 git checkout 7941972 Library/Formula/gradle.rb

1.0 git checkout dff67fb Library/Formula/gradle.rb

1.0-rc-3 git checkout 5f9e348 Library/Formula/gradle.rb

1.0-rc-2 git checkout f72e33f Library/Formula/gradle.rb

1.0-rc-1 git checkout e2438cf Library/Formula/gradle.rb

1.0-milestone-9 git checkout c27c667 Library/Formula/gradle.rb

1.0-milestone-8a git checkout 69eb948 Library/Formula/gradle.rb

1.0-milestone-8 git checkout 34da975 Library/Formula/gradle.rb

1.0-milestone-7 git checkout 6a8c437 Library/Formula/gradle.rb

1.0-milestone-6 git checkout dae625d Library/Formula/gradle.rb

1.0-milestone-5 git checkout baff305 Library/Formula/gradle.rb

1.0-milestone-3 git checkout d9f2e06 Library/Formula/gradle.rb

1.0-milestone-4 git checkout 4b1230c Library/Formula/gradle.rb

1.0-milestone-2 git checkout 6801464 Library/Formula/gradle.rb

1.0-milestone-1 git checkout 0476235 Library/Formula/gradle.rb

0.9.2 git checkout 38b9338 Library/Formula/gradle.rb

0.9.1 git checkout f986d7d Library/Formula/gradle.rb

0.9 git checkout 45e09d7 Library/Formula/gradle.rb

0.8 git checkout e6f608f Library/Formula/gradle.rb

可以看到，支持 1.9 版本的。

2. 进入 brew 所在的git仓库

$ cd `brew --prefix`

1	$ cd `brew --prefix`

3.复制粘贴刚才 brew versions gradle 命令的提示,我们需要1.9 版本的，因此执行

$ git checkout 5bab5e9 Library/Formula/gradle.rb

1	$ git checkout 5bab5e9 Library/Formula/gradle.rb

此时，本地仓库中的gradle 就被替换成了 1.9 的链接地址信息。

4. 安装

$ sudo brew install gradle
==> Downloading http://services.gradle.org/distributions/gradle-1.9-bin.zip

1 2	$ sudo brew install gradle ==> Downloading http://services.gradle.org/distributions/gradle-1.9-bin.zip

可以看到输出的信息已经是 1.9 的版本了。

2024 年 12 月
一	二	三	四	五	六	日
						1
2	3	4	5	6	7	8
9	10	11	12	13	14	15
16	17	18	19	20	21	22
23	24	25	26	27	28	29
30	31

前言

1 .gradle顶级目录

2 caches目录

2.1 caches/modules-2目录

2.1.1 files-2.1的目录组织（jar/aar都下载到这里）

3 daemon目录（无需离线）

4 native目录（无需离线）

5 wrapper目录

6. 使用.gradle/caches/modules-2创建jcenter的方法

参考链接

问题描述

修改过程中遇到的错误信息

不是很完美的解决问题

参考链接

参考链接

参考链接

下载Jenkins

下载Gradle

安装Tomcat

安装Jenkins

安装Git plugin,Gradle plugin,Android Lint Plugin插件

系统配置

新建项目

构建项目

检验构建结果

参考链接

下载`Jenkins`

下载`Gradle`

安装`Jenkins`

安装`Git plugin`,`Gradle plugin`,`Android Lint Plugin`插件
